Atoll DAC100 Signature black

The USB (B type) input allows the conversion of files to 24 bit/192 kHz and DSD64 & DSD128 Improvement of audio stages with MKP capacitors   Connect: ? 3 Optical Inputs ? 3 coaxial Inputs ? 1 USB Input (B type) ? 1 RCA stereo Output ? 2 digital Outputs (Optical & coaxial) Technical details: ? 2 independent transformers (including a reserved to audio analog) ? 7 regulated supplies ? D/A converter: BURR BROWN PCM1796 ? Output stages with discrete components without feedback ? MKP condensators for audio links ? Accepted format for the USB input: 24bits (32kHz, 44,1kHz, 48kHz & 96kHz, 192kHz, DSD64 & DSD128) ? Accepted format for optical and coaxial inputs: 16?24bit (44,1kHz, 48kHz, 96kHz and 192kHz)   The DAC100 Signature can be used with the remote ATOLL (optional) for: Inputs selection The attenuation of the output level   Dimensions: 320*210*60 mm Weight: 2 Kg Black or silver finish available   Frequency Response 20 Hz – 20 kHz (± 0,1 dB) THD at 1 Khz (0 dBF) <0,001% 24 bits Signal/Noise ratio 123dB Dynamic 123dB Output level 2.5 Vrms
